AI Series Vision Controller
HC-SYS945-40U
Intel® Core™ i7-12700 machine vision processor with AI-specific I/O, real-time control, and expandable design
Combining embedded PC technology, expanded functionality, optimized size, and robust construction, MSTAR TECHNOLOGIES' vision controllers are ideal for manufacturing facilities. These industrial computing platforms deliver desktop-level performance, easily monitoring one or multiple production lines. When paired with additional boards, they offer versatile options for image acquisition, network interfaces, processing offloading, and acceleration. Our advanced vision controller technology supports high-speed imaging for single or multi-camera installations, ensuring efficient, reliable operations.
Features
Intel® Core™ i7-12700 Processor
Base frequency of 2.1GHz, turbo up to 4.9GHz for exceptional performance
Integrated Vision-Specific I/O
Expandable digital I/O for precise control of external devices
AI-specific interfaces designed for advanced vision system functionality
High-Speed Camera Interfaces
2 Gigabit Ethernet ports (LAN1-LAN2) for up to 16 camera connections
6 USB3.0 ports for fast peripheral connections
6 serial ports (COM x6) for versatile communication
HDMI/DVI video interfaces for flexible display options
Power and Mechanical Design
850W power supply for reliable operation.
Dimensions: 430mm (W) x 177mm (H) x 450mm (D)
weight: 15kg
Designed for industrial environments with flexible installation options
Parameter
Item Category | Specific Item | Technical Specifications |
Processor | CPU | i7-12700, Base Frequency: Max Turbo Frequency 4.9GHz |
Chipset | Intel Q670 | |
Memory | RAM | 32GB DDR4 (Optional Configuration) |
Storage | 1TB SSD (Optional Configuration) | |
Display | Analog Interface | VGA |
Digital Interface | HDMI/DVI | |
Discrete Graphics Card Interface | 2080TI (Optional Configuration) | |
Camera Network Port | Gigabit Ethernet Port | LAN1-LAN2 |
Control | USB Port | USB2.0 x2, USB3.0 x6 |
Serial Port | COM x6 | |
Gigabit/10-Gigabit Network Card | Optional Configuration | |
Digital I/O | DIO (Digital Input/Output) | Optional Configuration |
Operating System | Microsoft Windows | Win10 Enterprise Edition 64bit |
Power Supply | Power Adapter Output | 850W |
Mechanical Parameters | Construction | N/A |
Mounting | N/A | |
Dimensions | 430mm (W) x 177mm (H) x 450mm (D) | |
Weight | 15kg | |
Environmental Adaptability | Operating Temperature | 0°C~50°C |
Storage Humidity | 10~90% RH @ 40°C (Non-condensing) | |
Storage Temperature | -20°C~75°C (Air Flow) | |
Vibration | 5 Grms / 5~500Hz / Random / Operating (SSD); 1 Grms / 5~500Hz / Random / Operating (HDD) | |
Shock | 50G Peak Acceleration (11ms Duration) (SSD); 20G Peak Acceleration (11ms Duration) (HDD) | |
EMC/Certification | N/A |
Dimension
Optional Accessories
